Mini PC Android
MINI-PC-ANDROID
CPU | Rockchip RK3399 ARM 6 cœurs 64 bits 2,0 GHz |
GPU | Mali - GPU T864 |
PMU | RK808 |
Mémoire | LPDDR double 4 Go |
Stockage interne | Flash EMMC de 16 Go |
la communication | WiFi IEEE 802.11 a / b / n / ac, RJ45 10/100 / 100M, Bluetooth 5.0 |
l'audio | Entrée / sortie micro Jack 3,5 mm |
Sortie vidéo | 1 x HDMI 2.0 (Type A) Prend en charge jusqu'à 4K @ 60 FPS / 1 x DP 1.2 (Display Port) Prend en charge jusqu'à 4K @ 60 FPS |
USB | 2 x HÔTE UBS 2.0, 1 x HÔTE USB 3.0, 1 x USB 3.0 Type C |
RTC | Prise en charge |
Débogage UART | Pris en charge 3 broches |
GPIO | GPIO1 40 broches (1 x I2S, 2 x I2C, 1 x SPI / UART, 8 x GPIO) / GPIO2 24 broches PCIE port |
Systèmes d'exploitation pris en charge | Android 8.1 / Ubuntu 16.04 / Ubuntu 18.04 / Debian 9 |
Alimentation | Prise jack: DC 5V / 3A, Type C: 5V / 3A |
Dimensions | 55,7 (L) x 91 (Fo) mm |
